FortiGate-3500F Hardware plus 5 Year Hardware plus FortiCare Premium and FortiGuard Enterprise Protection

Tilgjengelighet: Ikke på lager
Sku: FG-3500F-BDL-809-60
12 649 736,00 kr eksl mva
Send til
*
*
Fraktmetode
Navn
Estimert leveringsdato
Pris
Ingen fraktalternativer
Beskrivelse

The FortiGate 3500F series delivers high-performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high-throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage industry-leading IPS, SSL inspection, and advanced threat protection to optimize your network's performance. Fortinet's SecurityDriven Networking approach provides tight network integration to the new security generation.

  • Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
  • Protects against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic
  • Prevent and detect against known and unknown attacks using continuous threat intelligence from AI-powered FortiGuard Labs security services
  • Delivers industry's best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
  • Provides industry-leading performance and protection for SSL encrypted traffic
  • Delivers advanced networking capabilities that seamlessly integrate with advanced layer 7 security and virtual domains (VDOMs) to offer extensive deployment flexibility, multi-tenancy and effective utilization of resources
  • Delivers high-density, flexible combination of various high-speed interfaces to enable best TCO for customers for data center and WAN deployments
  • Includes a management console that is effective, simple to use, and provides comprehensive network automation and visibility
Generelt
EnhetstypeSikkerhetsapparat
Tjenestebundter5 år FortiCare Premium Support + 5 år FortiGuard Enterprise Protection
Høyde (Stativenheter)2U
Bredde44.3 cm
Dybde55.6 cm
Høyde8.9 cm
Vekt19.9 kg
Prosessor / Minne / Lager
Installerte prosessorerFortinet FortiASIC CP9/NP7
Nettverkstilknytning
ProduktformfaktorRackmonterbar
LuftflytretningFront til bakside-luftflyt
OverføringsteknologiKablet
DatakjedeprotokollGigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet
Nettverks-/transportprotokollTCP/IP, UDP/IP, IPSec, SCTP, HTTP, HTTPs, IPv4, IPv6
Protokoll for fjernstyrt administrasjonHTTP, HTTPS
YtelseIPS-gjennomløp (firmatraffikkblanding): 72 Gbps
NGFW-gjennomløp (bedriftstrafikkmiks): 65 Gbps
Trusselbeskyttelsesgjennomløp (bedriftstrafikkmiks): 63 Gbps
Brannveggjennomløp (1518-byte UDP): 595 Gbps
Brannveggjennomløp (512-byte UDP): 590 Gbps
Brannveggjennomløp (64-byte UDP): 420 Gbps
IPv6 bannmur-gjennomløp (1518-byte UDP): 595 Gbps
IPv6 bannmur-gjennomløp (512-byte UDP): 590 Gbps
IPv6 bannmur-gjennomløp (86-byte UDP): 420 Gbps
Brannvegglatens (64-byte UDP): 2.98 µs
Brannmurgjennomløp: 630 Mpps
VPN-gjennomstrømning (512-bit IPSec): 165 Gbps
VPN-gjennomløp (SSL): 16 Gbps
SSL inspeksjonsprosessering: 55 Gbps
Applikasjonskontroll-gjennomløp: 135 Gbps
CAPWAP-gjennomløp: 65 Gbps
KapasitetSamtidige TCP-økter: 140000000
Nye TCP-økter per sekund: 1000000
Brannmurspolitikk: 200000
Gateway-til-gateway IPSec VPN-tunneller: 40000
Klient-til-gateway IPSec VPN-tunneller: 200000
Samtidige SSL VPN-brukere: 30000
SSL inspeksjons-CPS: 60000
SSL-inspeksjon av samtidige økter: 15000000
Virtuelle domener: 10
Maksimum virtuelle domener: 500
Antall FortiSwitches: 300
Antall FortiAP-enheter: 4096
Antal FortiAP-enheder (tunnel): 2048
Antall FortiToken-enheter: 20000
StatusindikatorerStrøm, status, alarm, HA
EgenskaperVPN-støtte, Trusted Platform Module (TPM), CAPWAP-støtte, SSL-kontroll, IP-tunnelakselerasjon
KrypteringsalgoritmeSSL, 256-bit AES, 256-bits SHA, TLS 1.3
Ekspansjon / Tilkoplinger
Grensesnitt1 x USB 3.0
1 x konsoll - RJ-45
2 x 1 Gigabit Ethernet/10 Gb Ethernet (administrasjon) - RJ-45 (WAN)
2 x 10Gb Ethernet/25Gb Ethernet (HA) - SFP+/SFP28
30 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - SFP/SFP+/SFP28
6 x 40Gb Ethernet/100Gb Ethernet - QSFP+/QSFP28
Diverse
Tilleggsutstyr inkludert2 x SR 10Gbps SFP+ transceivere
Tilpassede standarderUL, VCCI, ICSA IPSec-godkjent, ICSA Firewall-godkjent, cUL, ICSA Antivirus, CB, FCC Part 15 A, RCM, ICSA SSL-VPN, ICSA IPS, ICSA IPv6, ICSA USGv6
Strømforsyning
StrømenhetIntern strømforsyning - hot-plug
Installert antall2
Max støttet Ant2
StrømforsyningsredundansJa
Påkrevd nettspenningAC 100-240 V (50/60 Hz)
Strømforbruk ved drift760 watt
Programvare / Systemkrav
OS MedfølgerFortiOS
Miljøparametere
Min. driftstemperatur0 °C
Maks. Driftstemperatur40 °C
Driftsfuktighet20 - 90% (ikke-kondenserende)
